MRepeater integration, MWC01 Badge Bluetooth-Repeater Und MBT02 Asset Bluetooth-Repeater. MWC01 performs accurate personnel management, with high accuracy and emergency response abilities.
The MBT02 is Minew’s innovative mobile asset repeater performing asset tracking with efficiency. It is embedded with a low-power Bluetooth chip for reliable broadcasting and scanning. Besides, MBT02 offers two scanning modes: periodic and movement-triggered. The repeater detects nearby Bluetooth beacons, filters and broadcasts the strongest signal to the gateway, enhancing the performance of asset tracking and usage monitoring. It reduces costs associated with Bluetooth gateways and maintenance requirements, thanks to its lightweight design and snap button for easy attachment and detachment of alarms.
Both MWC01 and MBT02 are cutting-edge ideal hardware solutions for personnel and asset management, contributing to enhanced operational efficiency and security in hospitals, buildings, warehouses, and many other heavily IoT-oriented industries.
MWC01 Badge Repeater
- High positioning accuracy
- Vibration feedback
- Intelligentes magnetisches Laden
- IP67 dust & water resistance
- Multiple RFID frequencies
MBT02 Asset Bluetooth® Repeater
- Two bluetooth® scanning options
- Disassembly alerts reminding
- 3 years service life
- Batch device management
- Flexible deployment
- Lightweight design
The MBT02 supports two modes: movement-triggered scanning and periodic scanning.
So funktioniert es
loT Gateway & Cloud Server
The gateway uploads the data to the cloud server. The cloud server analyzes and processes the data to achieve asset and people management functions.
Repeaters
The repeaters collect the Bluetooth signals broadcast by the beacons and then forward the data to the gateway.
Bluetooth-Beacon
Beacons are reasonably pasted to walls or pillars. Beacons broadcast Bluetooth signals in real-time.
Once Asset Repeater connected to the app or gateway platform and then disconnected while in the configurable state, it will automatically trigger a scan (based on the default scanning mode). Administrators can remotely initiate a scan by sending commands to the MBT02 via the Minew Tagcloud 3.0 platform, enabling them to receive the latest broadcast information and track the asset’s location and status.
Medical Asset Management
Ideal for medical asset management, MBT02 can be attached to equipment like tool carts, oxygen tanks, and beds. In periodic scanning mode, it continuously scans nearby beacons as assets move between departments or wards. This real-time tracking and monitoring of asset usage, duration, and location, significantly enhances the efficiency and accuracy of managing medical equipment in hospitals.
Warehouse Asset Movement Monitoring
The MBT02 is often used in large warehouses and factories, storing infrequently used assets. In movement scanning mode, it triggers Bluetooth® scanning as soon as the asset moves and stops. This feature provides real-time tracking of asset usage and movement patterns, enabling administrators with clear insights and enhanced transparency to optimize warehouse management and ensure asset security.
Cost-effective Indoor Positioning Solutions
The repeater solution reduces the deployment of Bluetooth gateways significantly, making it a cost-effective way for indoor location. Lower costs, and efficient, real-time asset tracking offer operational savings and flexibility in various industries.
Solutions for Improved Asset Security
MBT02’s anti-tamper switch and real-time tracking improve asset security. Receive immediate notifications for illegal access or removal, providing complete security and reducing the risk of asset loss.
People Management with Accuracy
With the MWC01’s Bluetooth location and emergency response functions, you can implement accurate staff management. Improve workplace safety and productivity by correctly detecting positions, allowing for quick replies in emergency circumstances.
Nahtlose Lösungen für vielfältige Szenarien
Industrial Workspaces
Office Environments
Gesundheitseinrichtungen
Lagerbestandsverfolgung
Spezifikationen
| Modell | MWC01 Badge Repeater | MBT02 Asset Bluetooth® Repeater |
| Material | ABS + PC | ABS |
| Gewicht | 19 g | 17 g |
| Schutz | IP67 | / |
| Batterie | 1 rechargeable battery, 290 mAh | Coin battery, 500 mAh |
| Akkulaufzeit | One charge – 16 days (Active time < 8 hours) |
3 years (default setting) |
| Sensor | Accelerometer | Accelerometer |
| Vibration Motor | ✔ | / |
| LED | 1 RGB light | Red |
| RFID | LF/ HF/ UHF optional | / |
| OTA | Unterstützt | Unterstützt |
| Konfigurations-App | MinewLink | MinewLink |
